Infrared Rad Guide Pillar Stone cutting machine 450 600 750
Product Type GHQJ-450 GHQJ-600 GHQJ-750
Blade Diameter 350-500MM 450-700MM 450-800MM
Max.Working Dimensions(L×W×H) 3200×3200×100(mm) 3200×3200×200(mm) 3200×3200×250(mm)
Table size 3200×2000(mm)
Working bench roating degree 0°-90°+45°/ 0°-45°-90°-360°
Blade Tiltable Degree 0°-85°
Main motor power 15kw 18.5kw 22kw
Gross power 20.2kw 23.7kw 27.3kw
Water consumption 3.5m³/h 3.6m³/h 3.6m³/h
Voltage 380v/50hz/3phase 380v/50hz/3phase 380v/50hz/3phase
Weight 6400kg 6600kg 6800kg
Overall Dimension 6000×4800×2900(mm) 6000×4800×3200(mm) 6000×4800×3500(mm)
Inregrated Bridge cutting machine GH-500
Max.working dimensions(L×W×H) 3200*3200*100(mm)
Diameter of blade 500 mm
Worktable dimensions(L×W) 3200*2000(mm)
Worktable tilting degree 0º-85°
Table rotating degree 90°
Main motor power 15kw
Water consumption 4m3/h
Overall dimensions(L×W×H) 6000*2700*22500(mm)
Hydraulic Bridge Cutting machine GH-2500
Blade Diameter : Φ1600- 2500mm
Saw blade number : 3-9slice
Max.Working Dimensions(L×W×H) :3500x2500x1100mm
Movements itinerary(H):1400mm
Main motor power:45KW
Gross power :55KW
Water consumption :16 m3/h
Trolley dimension(LxWxH) :7500x5000x5500mm
The total weight: 12500KG
Edge cutting machine SYQ-600
Blade Diameter 300-500MM
Max.Working Dimensions(L×W×H) 2700×1100×180(mm)
Table size 2700×800(mm)
Working heads roating degree 0°-180°/ 0°-360°
Main motor power 7.5kw
Gross power 16.3kw
Water consumption 3m³/h
Voltage 380v/50hz/3phase
Weight 2500kg(3000)
Overall Dimension 4900(5600)×5000×3200(mm)
